Scenario: ASCII Data from a Variety of Instruments (VLITE)
CASE STUDY UNDER CONSTRUCTION
Tools at a Glance
Back to Scenarios
This case study describes an experiment that gathered data from
a range of atmospheric sensors, collected mostly in ASCII format.
Data files are converted to netCDF format using Unidata's Rosetta
data transformation tool, and data are made available using
Geode Systems' RAMADDA data server.
John Kaiser and Dr. Jay Shafer from Lyndon State University
are working on a project titled “Improving the Forecasting
of Weather Driven Outages and Long Term Renewable Energy
Production” which is funded by the nonprofit organization
Vermont Low Income Trust for Electricity (VLITE).
The project is part of the The Vermont Weather Analytics Center,
which is managed by the Velco Vermont Electric Power Company. Lyndon State is directly
involved with is seeking to better understand how
anticipated climate change will affect production
from Vermont's renewable energy sources.
Data used by the project are collected from four weather
stations, a variety of weather observing programs, and
resulting output data from WRF model simulations. The Lyndon
State team collects data from Citizen Weather Observing
Program (CWOP), Meteorological Assimilation Data Ingest
System (MADIS), MESOWEST, as well as the Vermont Weather
Analytics Center (VTWAC). Data from VTWAC's four weather
stations is uploaded into CWOP's cloud database every
fifteen minutes, and is then run through MADIS. The WRF
model that Lyndon State is using pulls its initial
conditions from MADIS, after being run through a North
American Mesoscale Forecasting System (NAM) Analyses. The
data from the four weather stations is therefore used
indirectly to set the initial conditions in the WRF model
after NAM has integrated the data, and is downloaded into
the WRF models when the data is available, at 0 and 12 Z.
The initial conditions are uploaded into a WRF model in GRIB
Tools Used for Data Processing and Analysis
Data from past weather events are also analyzed using a WRF
model. Volume of data being produced by Lyndon States
project is in the order of 1 to 5 TB with the WRF model
simulations making up the majority of the data produced. To
analyze past events Python RGIS is used.
Data Storage Strategy and Tools Used
The WRF output data is natively output in netCDF format and
stored on the Vortex00 internal data server. Data is then
pulled from Vortex00 and ran through the Unified Post
Processor (UPP) is used to convert from netCDF format to a
GRIB format. Lyndon state then runs GRaDS on these GRIB
files to produce images.
Data Access Strategy and Tools Used
Sample output from the WRF model
(Click to enlarge)
Images that have been produced from the GRIB files are
stored on a web server for public access. The link to that
webpage can be found here. Currently the data is not
archived but is stored internally on Lyndon State's network.
Data Archiving Stragegy and Tools Used
